Alligator^® Size APF-100

Alligator^® Size APF-100

Ideal for applications where a mechanical fastener is desired, but cannot be used because of its metallic properties, APF-100 fasteners work on systems with a minimum pulley diameter of 1.5” (38 mm) and belt thicknesses up through 3/32” (2.4 mm).

Fastener Details

• Design: Hinged; one piece, molded rivets
• Belt Thickness: up through 3/32” (2.4 mm)
• Minimum Pulley Diameter: 1.5” (38 mm)
• PIW: 40 (7.0 kN/m)
• Hinge Pin Size: .096” (2.5 mm)
• Colors: White, Black, Blue
• Material Selection: Nylon
• Belt Width: 24” and 48” (600 mm and 1200 mm)
• Installation Method: Machine applied
